ST / PC - ST / PC Multinode 50 / 125 Fiber Optic Jumper Cable LSZH Orange Jacket
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | TRT |
| Certification: | ISO, CE |
| Model Number: | ST/PC MM DX 3.0mm |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | PP bag then in carton |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T, |
| Supply Ability: | 8000pcs/day |
|
Detail Information |
|||
| Material: | LSZH | Fiber: | MM 50/125 |
|---|---|---|---|
| Color: | Orange | Insertion Loss: | < 0.2dB |
| Polished: | PC | Length: | 1M,3M, 5M Or Custom |
| Highlight: | fiber optical cable,fiber optic network cable |
||
Product Description
ST/PC-ST/PC Multinode 50/125 fiber patch cable LSZH orange Jacket
Description:
- Type: ST/UPC-ST/UPC-MM-DX-3.0mm-3M
- Mode: Multimode
- Ferrule End-face: PC, UPC
- Cable core: Duplex
- Cable diameter: 2.0mm, 3.0mm
- Cable length: 1m, 2m, 3m….customized
Application:
Telecommunication
CATV, FTTH, LAN
Fiber oiptic sensors
Optical transmission system
Test equipment
Features:
Screw-thread coupling mechanism
Ceramic ferrules connectors
Low insertion loss, high return loss
Excellent mechanical endurance
High credibility and stability
Good in repeatability and exchangeability
100% Insertion, Return Loss, End Face and Interference inspection
Technical Data
Parameter |
Unit |
FC, SC, LC |
ST, MU |
MTRJ, MPO |
|||||||||
SM |
MM |
SM |
MM |
SM |
MM |
SM |
|||||||
PC |
UPC |
APC |
PC |
PC |
UPC |
PC |
PC |
UPC |
PC |
PC |
APC |
||
Insertion Loss |
dB |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
≤0.3 |
≤0.3 |
Return Loss |
dB |
≥45 |
≥50 |
≥60 |
≥30 |
≥45 |
≥50 |
≥30 |
≥45 |
≥50 |
≥35 |
≥55 |
≥75 |
Repeatability |
dB |
≤0.1 |
|||||||||||
Durability |
dB |
≤0.2dB typical change, 1000 matings |
|||||||||||
Operating temperature |
ºC |
-20 ~ +75 |
|||||||||||
Storage temperature |
ºC |
-40 ~ +85 |
|||||||||||
Ordering Information
Connector |
Fiber Core |
Cable Diameter |
Fiber Type |
Polishing |
Cable Jacket |
Cable Color |
Fiber Length |
LC SC FC ST D4 MU DIN SMA MPO MTRJ |
Simplex Duplex |
0.9mm 2.0mm 3.0mm |
SM:9/125um MM:50/125um MM:62.5/125um OM3 |
PC UPC APC |
PVC LSZH |
Yellow Orange Aqua others |
1M 2M 3M 10M 20M 30M |
