FC LC ST SC MPO Fiber Optic Patch Cord SM MM SX DX Multi core
Product Details:
| Place of Origin: | China |
| Brand Name: | TTI |
| Certification: | ISO CE UL RoHS |
| Model Number: | FC LC ST SC MPO |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | PE bag in carton with test cable |
| Delivery Time: | 2-5 days |
| Payment Terms: | T/T, L/C, , paypal |
| Supply Ability: | 8000 pieces perday |
|
Detail Information |
|||
| Brand Name: | TTI | Color: | Customized |
|---|---|---|---|
| Type: | LC-FC | Core: | Duplex |
| Dimension: | 2.0/3.0mm | ||
| Highlight: | multimode fiber patch cord,fiber optical cable |
||
Product Description
MANY HIGH QUALITY WITH LOWER PRICE IS MADE, MOST OF OUR CUSTOMERS WILL PLACE REPEAT ORDERS TO US!
Packaging Details:
wooden drum
Delivery Detail:
3-5 days
Duplex Multimode LC-SC 50/125 OM2 PVC 3.28ft(1m) Fiber optic patch cord
Description
The patch cord is made by 2.0mm or 3.0mm PVC sheath simplex or duplex indoor cable and then is completed with SC. ST. FC or LC connectors.
It provides a stable and reliable connection both SM or MM and single or dual fiber. PC, UPC and APC is optional.
- Low insertion loss.
- High return loss.
- High stability and reliability.
Multimode lc-lc duplex fiber optic l patch cords,lc-lc mm dx fiber patch cord:
Optical Fiber LC-LC
2.0mm/3.0mm loose tube
1:SX/DU-SM/MM
2:0.9/1.8/2.0/2.4/3.0mm
Optical Fiber LC-LC
1:SX/DU-SM/MM
2:0.9/1.8/2.0/2.4/3.0mm-Various color
3:OEM offered
4:ROHS, ISO9001
1:SX/DU-SM/MM
2:0.9/1.8/2.0/2.4/3.0mm-Various color
3:OEM offered
4:ROHS, ISO9001
1.Description
Sichuan Tianyi Comheart Opto-electronic Co. ltd’s Connectors are built under test of industrial standard, meet TIA/EIA-568-8.3 AND iso/iec 11801:202 Ed2.0, Telcordia (Belicore) GR-326-Core. Singlemode fiber connectors and patch cord requirement. IEC874-1 fiber connector and cable instruction, based on TIA/EIA-568 standard on A-8 designing, 568SC ZIP patch cords are internal cross-over, A-B to B-A, suitable for MTRJ-MTRJ and LC-LC and hybird patch cord. (568SC-ST, 569SC-MTJ and MTRJ-ST compatible duplex patch cord). All patch cords are label with printing on the cable.
2.Feature
Lower Insertion Loss
High Return Loss
Excellent Repeatability ,exchangeability, wearability and stability
Environmentally Stable
3.Applications
Telecommunications or Data communications
Telecommunications, Military industry, Medical,
CATV, LAN, MAN, WAN, Test & Measurement
Systems Integration for Railway, Metro and Access Network
Fiber to the Indoor (FTTX) Test
4.Fiber Optic Patch Cord Availabilities:
Full specifications, FC, SC, ST, LC, MTRJ, DIN, D4, SMA, etc.
Simplex and Duplex assemblies available
Singlemode and multimode available
PC, UPC and APC polishing available
PVC and LSZH outer sheath.
0.9mm, 2.0mm and 3.0mm cable size.
Hybrid patch cords are available upon request
Fan-out available (Ribbon type / bundle type)
Pigtail available
Loopback available
Customized length
Technical parameter
| Characteristic | SM , MM | |||
| Connector type | FC/SC/ST/LC/MU/MT-RJ/ESCON | |||
| Diameter(mm) | 0.9,2.0,3.0 | |||
| Polishing grade | SM PC | MM PC | UPC | APC |
| Insertion loss | ≤0.3dB | ≤0.4dB | ≤0.2dB | ≤0.3dB |
| Return loss | ≥40dB | ≥50dB | ≥65dB | |
| Interchangeability | ≤0.2dB | |||
| Repeatability | ≤0.2dB | |||
| Operation temperature | -40~+80 | |||
