OM1 OM2 Orange Fiber optic patch cord OS1 OS2 MM SX DX multicore can be customized
Product Details:
| Place of Origin: | China |
| Brand Name: | TTI |
| Certification: | IOS UL CE RoHS |
| Model Number: | OM1 OM2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | PE bag in Carton |
| Delivery Time: | 2-5days |
| Payment Terms: | L/C, T/T, , paypal |
| Supply Ability: | 10000 pieces perday |
|
Detail Information |
|||
| Model Number:: | SC/UPC MM DX Fiber Patch Cord | Boots: | 12 Colors Boots |
|---|---|---|---|
| Cable Diameter:: | 2.0mm Or 3.0mm Or 1.6mm Or 2.8mm | Length: | 3m,5m Any Length Is Ok |
| Connector: | Singlemode Or Multimode | Cable: | Simplex Or Duplex Or 6 -144 Fiber Cores |
| Insertion Loss: | Less Than 0.3dB | Duplex: | With Duplex Clips Or Not |
| A.B Ring: | With A.B Ring Or 1.2 Ring | Polising: | Upc, PC Or APC |
| Highlight: | multimode fiber patch cord,fiber optical cable |
||
Product Description
OM1 OM2 Orange Fiber optic patch cord OS1 OS2 MM SX DX multicore can be customized
Optical Fiber Optic Cable/Patch Cord, indoor cable,SC/UPC-SC/UPC multi-mode duplex, 1.6mm/2.0mm/3.0mm, with SC Optical Connector,China Factory made, OEM price fiber optic patch cords. Made in China, accept small order, supply free samples.
OM1 OM2 3meters 10G sfp+ cable
Description
10g sfp+ cable is a high performance, low power consumption, long reach interconnect solution supporting 10G Ethernet, fiber channel and PCIe. It is compliant with the QSFP MSA and IEEE P802.3ba 40GBASE-SR4. QSFP AOC is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 10Gb/s, providing an aggregated rate of 40Gb/s.
Feature
♦ Full duplex 4 channel 850nm parallel active optical cable
♦ Transmission data rate up to 10.3Gbit/s per channel
♦ SFF-8436 QSFP+ compliant
♦ Hot pluggable electrical interface
♦ Differential AC-coupled high speed data interface
♦ 4 channels 850nm VCSEL array
♦ 4 channels PIN photo detector array
♦ Multi-mode optical fibre cable of up to 100m
♦ Management Interface and digital diagnostic monitoring through I2C
♦ Low power consumption
♦ Housing isolated from connector ground
♦ Operating case temperature 0°C to +70°C
♦ 3.3V power supply voltage
♦ RoHS 6 compliant
Applications
♦ Infiniband transmission at 4ch SDR, DDR and QDR
♦ Switches, Routers
♦ Data Centers
♦ 4-channels 10Gb Ethernet or 8.5Gb Fiber Channel transmission
Fiber optical patch cord Complies with IEC, Telcordia GR-326-CORE standard
Low insertion loss and high return loss.
PC/UPC/APC polishing
Fiber cable diameter: 0.9, 2.0, and 3.0mm
Fiber optic cable single mode or multi mode is available
Fiber simplex or duplex is available
10G fiber or LSZH cable is available
Excellent changeability and repeatability
Tensile strength: 10N
Operating temperature range: -40 to 80° C
Storage temperature range: -40 to 80° C
Color of cable: Yellow (SM), Orange (MM), and Aqua (OM3),12 cable colors is available
Place of Origin:Guangdong, China (Mainland)
Brand Name:TTI
Color:Customized
Connector type:SC/FC/LC/ST
Polishing:PC/UPC/APC
Fiber Type:Singlemode/Multimode
Cable Diameter:3mm,2mm,0.9mm
RL:≥50dB
IL:≤ 0.3dB
Using temperature:-40~+80℃
Packaging Details
pe bag in carton with test cable
Delivery Time
2days
MANY HIGH QUALITY WITH LOWER PRICE IS MADE, MOST OF OUR CUSTOMERS WILL PLACE REPEAT ORDERS TO US!
Optical Fiber Cable Features
1. PC, UPC, APC polished
2. Male, female optional(For MPO MTRJ)
3. High return loss, low insertion loss
4. High reliability, high temperature stability
5. Good exchangeability
6. Push pull structure, compact size, dense type
Optical Fiber Cable Applications
* CATV, Metro, Test equipment
* Telecommunication networks
* Wide Area networks(WANS)
* Data processing networks
* Local area netwirks(LANS)
* Premise installations
Fiber Optic Patch Cord Technical Standard:
Insertion Loss: PC≤0.3dB, UPC≤0.3dB, APC≤0.3dB ;
Return Loss: SM PC≥50dB, UPC≥55dB, APC≥60dB; MM PC≥35dB, UPC≥35dB
Interchangeability: ≤0.2dB
Salt Spray : ≤0.2dB
Repeatability : (1000 times) ≤0.1dB
Vibration: (550Hz 1.5mm) ≤0.1dB
High Temperature : ( +85 sustain 100 hours) ≤0.2dB
Low Temperature : (-40 sustain 100 hours) ≤0.2dB
Temperature Circularly: (-40+85 sustain 100 hours) ≤0.2dB
Humidity : (+25+65 93 R.H.100 hours) ≤0.2db
Apex Offset: 0μm≤≤50μm
Radius of Curvature: 7mm≤≤25mm
Cable TypeSimplex, Duplex, Fan-Out;
Technical parameter
| Characteristic | SM , MM | |||
| Connector type | FC/SC/ST/LC/MU/MT-RJ/ESCON | |||
| Diameter(mm) | 0.9,2.0,3.0 | |||
| Polishing grade | SM PC | MM PC | UPC | APC |
| Insertion loss | ≤0.3dB | ≤0.3dB | ≤0.3dB | ≤0.3dB |
| Return loss | ≥40dB | ≥55dB | ≥60dB | |
| Interchangeability | ≤0.2dB | |||
| Repeatability | ≤0.2dB | |||
| Operation temperature | -40~+80 | |||
